内徑
|
外徑
|
寬度 B
|
倒角
|
额定實荷Load Rating
|
|
|
型號
|
動負荷
|
静負荷
|
参考
|
|
|
d
|
D
|
開式
|
闭式
|
Ｒ
|
Cr
|
Cor
|
重量
|
|
|
mm inch
|
mm inch
|
mm inch
|
mm inch
|
mm inch
|
N
|
N
|
kg
|
|
R2
|
3.175
|
0.125
|
9.525
|
0.375
|
3.969
|
0.1563
|
3.969
|
0.1563
|
0.3
|
0.012
|
640
|
226
|
0.0014
|
|
R2A
|
3.175
|
0.125
|
12.7
|
0.5
|
4.366
|
0.1719
|
4.366
|
0.1719
|
0.3
|
0.012
|
640
|
226
|
0.0033
|
|
R3
|
4.762
|
0.1875
|
12.7
|
0.5
|
3.969
|
0.1563
|
4.978
|
0.1563
|
0.3
|
0.012
|
1310
|
485
|
0.0029
|
|
R4
|
6.35
|
0.25
|
15.875
|
0.625
|
4.978
|
0.196
|
4.978
|
0.196
|
0.3
|
0.012
|
1470
|
600
|
0.0045
|
|
R4A
|
6.35
|
0.25
|
19.05
|
0.75
|
5.556
|
0.2187
|
7.144
|
0.2183
|
0.4
|
0.016
|
2410
|
911
|
0.01
|
|
R6
|
9.525
|
0.375
|
22.225
|
0.875
|
5.556
|
0.2187
|
7.144
|
0.2183
|
0.4
|
0.016
|
3350
|
1410
|
0.0117
|
|
R8
|
12.7
|
0.5
|
28.575
|
1.125
|
6.35
|
0.25
|
7.938
|
0.3125
|
0.4
|
0.016
|
5110
|
2380
|
0.021
|
|
R10
|
15.875
|
0.625
|
34.925
|
1.375
|
7.144
|
0.2813
|
8.731
|
0.3437
|
0.8
|
0.032
|
6000
|
3250
|
0.0367
|
|
R12
|
19.05
|
0.75
|
41.275
|
1.625
|
7.938
|
0.3125
|
11.112
|
0.4375
|
0.8
|
0.032
|
8370
|
4520
|
0.063
|
|
R14
|
22.225
|
0.875
|
47.625
|
1.875
|
9.525
|
0.375
|
12.7
|
0.5
|
0.8
|
0.032
|
10060
|
5920
|
0.107
|
|
R16
|
25.4
|
1
|
50.8
|
2
|
9.525
|
0.375
|
12.7
|
0.5
|
0.8
|
0.032
|
10060
|
5920
|
0.107
|
|
R18
|
28.575
|
1.125
|
53.975
|
2.125
|
9.525
|
0.375
|
12.7
|
1.5
|
0.8
|
0.032
|
11900
|
7460
|
0.122
|
|
R20
|
31.75
|
1.25
|
57.15
|
2.25
|
9.525
|
0.375
|
12.7
|
0.5
|
0.8
|
0.032
|
13230
|
8300
|
0.125
|
|
R22
|
34.925
|
1.375
|
63.5
|
2.5
|
11.112
|
0.4375
|
14.288
|
0.5625
|
0.8
|
0.032
|
16210
|
10420
|
0.165
|
|
R24
|
38.1
|
1.5
|
66.675
|
2.625
|
11.112
|
0.4375
|
14.288
|
0.5625
|
0.8
|
0.032
|
17030
|
11700
|
0.172
|
|
R144
|
3.175
|
0.125
|
6.35
|
0.25
|
2.779
|
0.1094
|
2.779
|
0.1094
|
0.08
|
0.003
|
294
|
98
|
0.0003
|
|
R155
|
3.969
|
0.1563
|
7.938
|
0.3125
|
2.799
|
0.1094
|
3.175
|
0.125
|
0.08
|
0.003
|
392
|
147
|
0.00055
|
|
R156
|
4.762
|
0.1875
|
7.938
|
0.3125
|
2.779
|
0.1094
|
3.175
|
0.125
|
0.08
|
0.003
|
392
|
147
|
0.0045
|
|
R166
|
4.762
|
0.25
|
9.525
|
0.375
|
3.175
|
0.125
|
3.175
|
0.125
|
0.08
|
0.003
|
715
|
274
|
0.0008
|
|
R168
|
6.35
|
0.1875
|
9.525
|
0.375
|
3.175
|
0.125
|
3.175
|
0.125
|
0.08
|
0.003
|
421
|
205
|
0.0006
|
|
R186
|
4.762
|
0.1875
|
12.7
|
0.5
|
2.779
|
0.1094
|
3.969
|
0.1563
|
0.13
|
0.005
|
1313
|
490
|
0.002
|
|
R188
|
6.35
|
0.25
|
12.7
|
0.5
|
3.175
|
0.125
|
4.762
|
0.1875
|
0.13
|
0.005
|
833
|
372
|
0.002
|
|
R1810
|
7.938
|
0.3125
|
12.7
|
0.5
|
3.969
|
0.1563
|
3.969
|
0.1563
|
0.13
|
0.005
|
882
|
421
|
0.0017
|
